$50.99
MOUGOL MG-X99 D4 Motherboard – LGA 2011-3, DDR4 ECC, Xeon E5 2680 V4 Bundle Product Description Build a high-performance workstation or gaming system with the MOUGOL MG-X99 D4 Motherboard, designed for...

DESCRIPCIÓN COMPLETA

MOUGOL MG-X99 D4 Motherboard – LGA 2011-3, DDR4 ECC, Xeon E5 2680 V4 Bundle

Product Description

Build a high-performance workstation or gaming system with the MOUGOL MG-X99 D4 Motherboard, designed for Intel Xeon E5 V3/V4 processors on the LGA 2011-3 socket. Featuring dual-channel DDR4 ECC memory support up to 128GB, PCIe 3.0, M.2 NVMe storage, and flexible bundle options including the 14-core Xeon E5 2680 V4 and DDR4 RAM, this Micro-ATX board delivers exceptional value for content creators, gamers, and budget-conscious builders.

Key Features at a Glance

Feature Details
Chipset Intel H55
CPU Socket LGA 2011-3
CPU Compatibility Intel Xeon E5 V3/V4 series
Form Factor Micro-ATX (215mm × 190mm)
Memory 4 x DDR4 slots, dual-channel, up to 128GB (32GB per slot)
Memory Type DDR4 ECC / Non-ECC server memory
Memory Speed 1600 / 1866 / 2133 / 2400 MHz
Storage 3 x SATA (1 SATA 3.0, 2 SATA 2.0), 1 x M.2 (2280/22110, NVMe/SATA)
PCIe Slots 1 x PCIe 3.0 x16, 1 x PCIe x1, 1 x PCI
USB Ports 6 x USB 2.0
LAN Gigabit Ethernet (Realtek)
Audio 2.1 channel (MIC-IN, LINE OUT, LINE IN)

Bundle Options

SKU Contents
Motherboard Only MG-X99 D4 motherboard, I/O shield, SATA cable, speaker connector
Motherboard + CPU MG-X99 D4 motherboard + Intel Xeon E5 2680 V4 processor
Motherboard + CPU + RAM MG-X99 D4 motherboard + Intel Xeon E5 2680 V4 + 1 x 8GB DDR4 RAM

⚠️ Note: Motherboard is brand new. CPU and RAM are used (tested and fully functional) and may show signs of use. New/old level of RAM and CPU cannot be controlled and is sent randomly.

Bundle Processor: Intel Xeon E5 2680 V4

Specification Details
Model Intel Xeon E5 2680 V4
Cores / Threads 14 cores / 28 threads
Base Frequency 2.4 GHz
Turbo Frequency 3.3 GHz
L3 Cache 35 MB
Manufacturing Process 14nm
TDP 120W
Memory Support DDR4 1600 / 1866 / 2133 / 2400 MHz
Socket LGA 2011-3

Features in Detail

🖥️ Intel Xeon LGA 2011-3 Platform

Built on an Intel H55 chipset, this motherboard supports Intel Xeon E5 V3 and V4 processors—ideal for high-core-count workloads including video rendering, virtualization, and multitasking.

💾 Dual-Channel DDR4 ECC Memory

With 4 memory slots supporting dual-channel architecture, the MG-X99 D4 handles up to 128GB of DDR4 RAM (32GB per slot).

Supported speeds: 1600MHz, 1866MHz, 2133MHz, 2400MHz

⚠️ Important Memory Installation Note:

  • All RAM must be installed first in slot #1 and slot #2 (orange slots)

  • The gray RAM slots (#3 and #4) will not work alone

  • Memory must be inserted into the same color slots

🚀 M.2 NVMe Storage

Includes 1 x M.2 slot supporting:

  • Formats: 2280 and 22110

  • Protocols: NVMe (PCIe) and SATA M.2

🎮 PCIe 3.0 Expansion

  • 1 x PCIe 3.0 x16 – Dedicated for graphics cards

  • 1 x PCIe x1 – Additional expansion

  • 1 x PCI – Legacy expansion support

🔌 I/O & Connectivity

Rear I/O Ports:

  • 6 x USB 2.0

  • 1 x PS/2

  • 1 x Gigabit Ethernet (RJ45)

  • 3 x audio jacks (MIC-IN, LINE OUT, LINE IN)

Onboard Headers:

  • 24-pin main power

  • 8-pin +12V CPU power

  • CPU fan connector

  • Front panel audio (AAFP)

  • Speaker connector

  • 3 x SATA ports (1 SATA 3.0, 2 SATA 2.0)

  • 1 x M.2 slot

📏 Micro-ATX Form Factor

Measuring 215mm × 190mm, this motherboard fits a wide range of cases.

Technical Specifications

Specification Details
Brand MOUGOL
Model MG-X99 D4
Chipset Intel H55
CPU Socket LGA 2011-3
CPU Compatibility Intel Xeon E5 V3/V4 series
Form Factor Micro-ATX (215mm × 190mm)
Memory Slots 4 x DDR4 (dual-channel)
Max Memory 128GB (32GB per slot)
Memory Type DDR4 ECC / Non-ECC server memory
Memory Speed 1600–2400 MHz
Storage 1 x SATA 3.0, 2 x SATA 2.0, 1 x M.2 2280/22110 (NVMe/SATA)
PCIe Slots 1 x PCIe 3.0 x16, 1 x PCIe x1, 1 x PCI
USB Ports 6 x USB 2.0
LAN Gigabit Ethernet (Realtek)
Audio 2.1 channel
RAID Support Yes
Origin Mainland China

Important Notes

⚠️ Before You Buy – Read Carefully

Note Details
Memory Installation Install RAM in orange slots (#1 and #2) first. Gray slots will not work alone.
Temperature Readings Motherboard does not have a temperature control chip. Software may show virtual temperatures (110°–120°). This is normal. Use a physical thermometer for actual temperature.
CPU & RAM Condition In bundles, CPU and RAM are used (tested and working). They may show signs of use. New/old level sent randomly.
Battery CMOS battery is removed before shipment due to logistics restrictions. Install a new CR2032 battery upon arrival.
Power Supply Requires at least 500W brand power supply with 24-pin and 8-pin CPU connectors.
Compatibility Niche brands, ES/QS versions of CPU/RAM/M.2 may be incompatible. Confirm with customer service before purchase if unsure.
Incompatibility If not confirmed before purchase, incompatibility issues will not qualify for refund.
Customs Buyer responsible for customs clearance and any applicable tariffs.

Recommended Components

Component Recommendation
CPU Xeon E5 2680 V4 (included in bundles) or other LGA 2011-3 Xeon V3/V4
Memory 4 x 32GB DDR4 ECC (install in orange slots first) – Samsung, Kingston, Micron, Hynix
Storage M.2 NVMe SSD + SATA SSDs/HDDs
GPU PCIe x16 graphics card
Cooler LGA 2011-3 compatible CPU cooler
PSU 550W+ brand power supply with 24-pin and 8-pin CPU connectors

Perfect For

  • Video Production: 14-core Xeon for rendering and encoding

  • Workstation Builds: Affordable server-grade platform with ECC memory support

  • Gaming on a Budget: Pair with dedicated GPU for solid performance

  • Content Creation: Video editing, 3D rendering, and streaming

  • Virtualization: 28 threads for VM workloads

  • Scientific Computing: ECC memory for data integrity

Build your next workstation or gaming rig with the MOUGOL MG-X99 D4 Motherboard—LGA 2011-3, DDR4 ECC memory, and bundle options with 14-core Xeon E5 2680 V4.
